Zirconia Ferrule Inner Diameter Polishing Wire
This product is high-strength piano wire having excellent precision and high roundness developed for polishing the inner diameter of zirconia ferrule, which is the core part of the optical communication connector.
Characteristics
- High-strength piano wire having high precision with a wire diameter tolerance of ±0.1μm
- Having high roundness with a diameter deviation of less than 0.2μm
- We perform adjustment of diamond dies in our company, enabling quick response to your desired wire diameter in increments of 0.1μm.
- Hard to break and excellent in durability with ultra-high cleanliness steel used for the base material.
Applications
- Polishing the inner diameter of zirconia ferrule
Specifications
| Product Name | Ferrule Polishing Wire |
|---|---|
| Diameter Range | 80μｍ–200μｍ (0.08mm–0.2mm) |
| Diameter Tolerance | ±0.1μm (±0.0001mm) |
| Diameter Deviation | 0.2μm or less (0.0002mm or less) |
| Packing Styles | Bobbin |
If you desire other wire diameter, please contact us.
